RPS-400-24-TF
252W 24VDC 16A Medical Enclosed Top Fan Type Power Supply Please ring us to discuss a great price for this product.Product Features
- 3 years warranty
- Suitable for BF application with appropriate system configuration
- Protections: Short circuit / Overload / Over voltage / Over temp
- 250W convection, 400W force air
- Medical safety approved (2x MOPP according to AAMI/ANSI ES60601-1 and IEC/EN60601-1
- "5 x "3 compact size
- EMI Class B for Class I and Class A for Class II configuration
- No load power consumption: 5V DC standby output, 12Vdc fan supply, Power Good, Power Fail and remote sense
Description
RPS-400 is a 400W highly reliable green PCB type medical power supply with a high power density on the 5” by 3” footprint. It accepts 80~264VAC input and offers various output voltages between 12V and 48V. The working efficiency is up to 94%, and the extremely low no-load power consumption is below 0.5W.RPS-400 (blank type) can be used for both Class I (with FG) and Class II (no FG) system designs. The extremely low leakage current is less than 160μA. In addition, it conforms to international medical regulations (2×MOPP) and EMC BS EN/EN55011, perfectly fitting all kinds of BF rated “patient contact” medical system equipment. RPS-400 series also offers the enclosed style models (-C / TF / SF). This range includes variations of an open frame PCB enclosed casing (-C), an enclosed casing with a fan on top (-TF) and an enclosed casing with a fan on the side (-SF).
Style
- Enclosed Top Fan
