PS-05-24
5.28W 24VDC 0.22A Industrial Open Frame Power Supply Please ring us to discuss a great price for this product.Product Features
- 2 years warranty
- Low cost
- Low leakage current < 0.5mA
- Cooling by free air convection
- High reliability
- Universal AC input / Full range
- Fixed switching frequency at 67 KHz
- 100% full load burn-in test
Description
The MEAN WELL PS-05-24 provides 24VDC output at 0.22A with 5.28W rated power from a compact open-frame format. Universal 85–264VAC or 120–370VDC input enables operation across a wide range of AC and DC supply systems, while typical efficiency reaches 76%. The fanless design relies on free-air convection cooling and operates from -10°C to +60°C. Low leakage current below 0.5mA and integrated short-circuit, overload, over-voltage and over-temperature protection support dependable operation within connected equipment. At just 75 × 40 × 20mm, the PS-05-24 provides a space-efficient 24V power solution with a 100% full-load burn-in test for added reliability.
