RPS-60-5
50W 5VDC 10A Medical Open Frame Power Supply Please ring us to discuss a great price for this product.Product Features
- Cooling by free air convection
- No load power consumption < 0.75W
- Operating altitude up to 3000 meters
- EMI class B for Class I configuration
- IT & Medical safety approved (2 × MOPP) according to ANSI/AAMI ES60601-1, IEC/BS EN/EN60601-1 and IEC/BS EN/EN/UL 62368-1
- 3 years warranty
- Suitable for BF application with appropriate system consideration
- 4" × 2" compact size
Description
Developed for medical and IT applications with the requirement of reduced profiles and complying with both medical and industrial agency standards, these units can deliver their fully rated output of 50 to 60W with only free air convection. Also having 10% more peak load capability than their larger rivals. Featuring only 200uA of leakage current at 264Vac they can be installed into non-patient contact medical equipment and still comply with Class B EMI regulations. Standard functions include no load power consumption for single output models as low as 0.75W which can be used in powering electronic equipment requiring the green mode facility. The reduced height of 29mm also makes the unit suitable for 1U applications or other height constraint applications.
