MFM-10-12
10.2W 12VDC 0.85A High Reliability Medical On Board Open Frame Power Supply Please ring us to discuss a great price for this product.Product Features
- 3 years warranty
- Extremely low leakage current
- Typical lifetime >52K hours
- 1.65"x0.88" compact size
- Medical safety approved (2XMOPP) according to ANSI/AAMI ES6060-1 and IEC/EN60601-1
- Wide operating temperature range -30 °C ~+85°C
- No minimum load required
- Suitable for BF application with appropriate system consideration
- No load power consumption <0.075W
- EMI class B for Class II configuration
Description
MFM-10-12 is a 10.2W 12V 0.85A high density and small sized AC/DC on-board type medical grade power supply. It has a high efficiency and operates from -80~264VAC. It features a no load power consumption of less than 0.075W Class II (no FG) double insulation, outstanding dissipation, 5G anti-vibration, high EMC performance and a 4KVAC isolation. The design observes IEC/EN60601-1 and ANSI/AAMI ES60601-1 version three with 2xMOPP level and ultra-low leakage current (
