MFM-20-12
21.6W 12VDC 1.8A High Reliability Medical On Board Open Frame Power Supply Please ring us to discuss a great price for this product.Product Features
- 1.93" × 0.94" compact size
- Suitable for BF application with appropriate system consideration
- ANSI/AAMI ES60601-1 and IEC/BS EN/EN60601-1
- Medical safety approved (2 × MOPP) according to
- No minimum load required
- Wide operating temp. range -35 ~ +85°C
- Extremely low leakage current
- EMI class B for class II configuration
- 3 years warranty
- No load power consumption < 0.1W
Description
MFM-20 is a 20W high density and small size (49 × 23.8 × 23mm) AC/DC on board type medical power supply series. It supports operation from 80~264VAC, with a no load power consumption below 0.1W, and achieves high efficiency up to 87%.It features Class II (no FG) double insulation, efficient heat dissipation, 5G anti-vibration performance, high EMC compliance, and 4KVAC isolation. The unit complies with IEC/BS EN/EN60601-1 and ANSI/AAMI ES60601-1 version three, with 2×MOPP insulation and ultra-low leakage current (
