IRM-45-5
40W 5VDC 8A PCB Mount Encapsulated Power Supply Please ring us to discuss a great price for this product.Product Features
- Wide operating temperature range: -30~70°C
- Universal input: 85~305VAC
- Cooling by free air convection
- EMI Class B without additional components
- Overvoltage category II
- Pass LPS (Except for 5V)
- 3 years warranty
- 3.43” × 2.05” compact size
- No load power consumption < 0.15W
- Isolation Class II
- PCB, chassis or screw terminal mounting version
Description
IRM-45 is a 45W miniature (87 × 52 × 29.5mm) AC-DC module-type power supply designed for direct soldering onto the PCB boards of a wide variety of electronic instruments and industrial automation systems. It accepts a universal input voltage range of 85~305VAC and uses a 94V-0 flame-retardant plastic case combined with silicone for improved heat dissipation.It is available in a standard PCB mounting style (Blank) that meets anti-vibration requirements up to 2G, and a screw terminal style model (ST) that withstands vibration up to 5G. This rugged design offers moisture and dust resistance, making it reliable for harsh environments.With a high efficiency of up to 90.5% and extremely low no-load power consumption below 0.15W, the IRM-45 series complies with international standards for low power electronics. It features Class II insulation (no FG pin) and built-in EMI filtering, complying with BS EN/EN55032 Class B standards to suppress electromagnetic interference.In addition to the standard PCB version, the IRM-45 is also available in a screw terminal version for added installation flexibility.
Style
- PCB
