IRM-90-15
85W 15VDC 5.67A PCB Mount Encapsulated Power Supply Please ring us to discuss a great price for this product.Product Features
- Overvoltage category III
- 3 years warranty
- 3.43” × 2.05” compact size
- Operating altitude up to 4000 meters (Note 7)
- Cooling by free air convection
- Universal input: 80~305VAC
- No load power consumption < 0.3W
- Wide operating temperature range: -30~+80°C
- 100W peak load (10 seconds)
- EMI compliance: BS EN/EN55032 Class B without additional components
- Isolation Class II
- PCB, chassis, or screw terminal mounting version
Description
IRM-90 is a 90W miniature (87 × 52 × 29.5mm) AC-DC PCB-mount power supply designed to be directly soldered onto the PCB boards of various electronic instruments or industrial automation devices. It supports a wide input voltage range of 80~305VAC and features a durable 94V-0 flame retardant plastic housing filled with silicone to assist in heat dissipation and vibration resistance (rated 25G depending on the version).With peak power capability up to 100W for 10 seconds and a high operating efficiency of up to 93%, it meets the rigorous demands of space- and energy-conscious electronics. The unit offers extremely low no-load power consumption of under 0.3W, making it ideal for systems that require compliance with global energy-saving standards.The IRM-90 series features Class II isolation (no FG pin) and built-in EMI suppression, conforming to BS EN/EN55032 Class B. In addition to the standard PCB mounting version, it is also available with a screw terminal style (ST) for easier wiring in field applications.
Style
- PCB
