MPM-90-48
90.2W 1.88A 48VDC High Reliability PCB-Mount Medical Power Module Please ring us to discuss a great price for this product.Product Features
- 3.43" x 2.05" compact size
- Operating altitude up to 4000 meters
- Protections: Short circuit / Overload / Over voltage
- Suitable for BF application with appropriate system consideration
- 100W peak (10 sec.)
- No load power consumption < 0.1W
- Extremely low leakage current
- No minimum load required
- PCB, chassis or screw terminal mounting version
- Wide operating temperature range: -30 ~ +80°C
- 3 years warranty
- Isolation Class II
- EMI Class B without additional components
- Medical safety approved (2 x MOPP) according to ANSI/AAMI ES60601-1 and IEC/BS EN/EN60601-1
Description
The MEAN WELL MPM-90-48 is a compact PCB-mount medical power module delivering 48VDC at 1.88A with 90.2W continuous convection-cooled output. Its 10-second peak capability increases output to 2.07A and 99.2W, supporting equipment with temporary higher power demands. The module accepts 80–264VAC or 113–370VDC input and achieves 93% typical efficiency. Medical safety performance includes 2 x MOPP isolation, ultra-low touch current and suitability for BF applications with appropriate system design. Class II insulation and EMI Class B performance support integration into sensitive medical equipment, complemented by short-circuit, overload, over-voltage and over-temperature protection. The compact PCB-mount design measures 87 × 52 × 29.5mm.
Style
- PCB Mount
