NGE90I18-P1J
90W 18VDC 5A Interchangeable Base Plug Top Adapter Please ring us to discuss a great price for this product.Product Features
- Global certificates in multi-fields (ITE 62368-1, Medical 60601-1, Household 60335-1, Industrial 61558-1/-2-16)
- No load power consumption < 0.1W
- Protections: Short circuit / Overload / Over voltage
- 3 years warranty
- Class II power (no earth pin)
- 30°C ~ +70°C wide range working temperature
- 80~264Vac Universal AC input
- Extremely low leakage current < 100μA
- Interchangeable AC plugs (I-Type)
- Various DC plug quick adapter accessories available
- Energy efficiency Level VI
- Ultra slim (30mm)
- MEAN WELL Patent Application Number: 202330347779.4
Description
NGE90 is a highly reliable, 90W wall-mounted style single-output green adaptor series, which is compact and convenient for carry. This product is equipped with 7 types of interchangeable AC plug (European, USA, U.K., Australian, China, Korea and India type) that makes it very suitable for travel use. NGE90 is a Class II power unit (no FG), accepting the input range from 80VAC to 264VAC that it can satisfy the demands for various types of electrical devices.With the working efficiency up to 92% and the extremely low no-load power consumption below 0.1W, NGE90 is compliant with the latest USA energy regulation EISA 2007/DoE, Canada NRCan, Australia and New Zealand MEPS, Korea KMEPS, EU ErP and CoC version 5. The supreme feature allows the adaptor to save the energy when it is under either the operating mode or the standby mode. The entire series is approved for ITE, medical, household and industrial appliance safety regulations; moreover, it adopts the 94V-0 flame retardant plastic case that it can effectively prevent users from electric hazard.
