VFD-750C-230
AC-AC Variable Frequency Drive with PFC Please ring us to discuss a great price for this product.Product Features
- Suitable for 3-phase motor drive (e.g., BLDC, Induction motor, SynRM)
- Fanless design for silent operation and long lifetime
- High peak current up to 200% and 5 seconds
- 90~264Vac input, built-in PFC boost to 380VDC
- Power stage, 3-phase switches with sensors in one unit for external control (control board VFD-CB sold separately)
- Protections: Short circuit / OCP
- 3 years warranty
- 30ºC ~ +60°C wide operating temperature
Description
The VFD-750C-230 is a universal variable frequency drive power module providing integrated power stage, gate drivers and basic VFD sensors such as three-phase output current and temperature sensors. This product can be implemented for a three-phase motor drive solution by coordinating with an external motor drive controller at the logic level and analogue I/O. The power stage input is single phase full range from 90VAC to 264VAC with PFC function. The 3-phase motor output is up to 240V with 200% peak current capability. The VFD-750C-230 is suitable for three-phase motor drives, such as BLDC, Induction motors, and SynRM applications.
