DDRH-45-15ST
45W 15VDC 3A Wide Input Screw Terminal DC-DC Converter Please ring us to discuss a great price for this product.Product Features
- 150~1500Vdc 10:1 ultra-wide input range
- Can be installed on DIN rail TS-35/7.5 or 15 (DR-Type)
- Fanless design, fully encapsulated, cooling by free air convection
- Operating altitude up to 5000 meters
- 3 years warranty
- 40 ~ +80°C ultra-wide operating temperature (> +50°C derating)
- 4KVac I/O high isolation (Reinforced isolation)
Description
DDRH-45 series is a 150 ~ 1500Vdc high reliable ultra-high input DC-DC converter which can supply stable working voltage for the load. Main features are as following: compact size, -40~+80°C wide range operating temperature, 4KVac high isolation voltage, operation at 5000m altitude, low ripple & noise, complete protections and so on. Furthermore, this series also has DIN Rail type, which is suitable for mounting on TS-35/7.5 or TS-35/15 rails.DDRH-45 is designed to meet the UL1741 and IEC62109-1 standards. It is suitable for industrial automation, surveillance, telecommunication and can be widely deployed in the applications of new energy generation, such as solar power, and windmill power generation, for instance, photovoltaic power systems, high voltage inverting, DC bus centralised application, ESS, charging pile, railway and so forth.
Style
- Screw Terminal
