SDX-450-G24
450W 24VDC Input ATX PC Power Supply Please ring us to discuss a great price for this product.Product Features
- Input and output isolation
- Soft start function, low inrush current
- UL, cUL, CB, CE standard
- 3 years warranty
- 100% full load burn-in test
- 5V output option
- High efficiency and reliability
- Meet Intel ATX 2.31
- 3.3V & 5V VRM design
Description
The SDX-450-G24 is a 450W ATX DC-DC power supply designed for systems running on a 24VDC input. Featuring a wide input range of 19V to 36V, this unit delivers multiple regulated outputs including 3.3V, 5V, dual 12V, -5V, -12V, and 5Vsb, making it suitable for complex system architectures.With protections such as over-voltage, over-load, and short circuit shutdowns, it ensures robust and stable power delivery. The integrated power good and PS-ON signals support intelligent power management. It includes input/output isolation and meets major safety and EMC standards such as UL, CE, and CB.Housed in a compact 150 x 140 x 86 mm casing with forced-air cooling, the SDX-450-G24 is built for high reliability, offering a typical efficiency of 80% and a minimum MTBF of 215,000 hours. This unit complies with Intel ATX 2.31 standards and includes a 3-year warranty.
